Spectrograms

This tutorial demonstrates how to use OpenSoundscape to create spectrograms from audio files, inspect spectrogram properties, and modify spectrograms.

Run this tutorial

This tutorial is more than a reference! It’s a Jupyter Notebook which you can run and modify on Google Colab or your own computer.

Link to tutorial	How to run tutorial
	The link opens the tutorial in Google Colab. Uncomment the “installation” line in the first cell to install OpenSoundscape.
	The link downloads the tutorial file to your computer. Follow the Jupyter installation instructions, then open the tutorial file in Jupyter.

# if this is a Google Colab notebook, install opensoundscape in the runtime environment
if 'google.colab' in str(get_ipython()):
  %pip install opensoundscape

Quick start

The “quick start” code below demonstrates a basic pipeline for downloading an audio file, loading it into OpenSoundscape, and creating a spectrogram from it

Import needed classes

Import the Audio and Spectrogram classes from OpenSoundscape.

(For more information about Python imports, review this article.)

# Import Audio and Spectrogram classes from OpenSoundscape
from opensoundscape import Audio, Spectrogram

#other utilities
from pathlib import Path

Get an example audio file

Here we download an example birdsong soundscape recorded by an AudioMoth autonomous recorder in Pennsylvania, USA.

audio_object=Audio.from_url('https://tinyurl.com/birds60s')
# or load a local file:
# a = Audio.from_file('/local/file/path')
audio_object
